MX250 MOTOCROSS SPECIFICATION | |
PRODUCT NAME | MX250 MOTOCROSS |
REGION | International |
EMISSION STANDARD | Chinese National Ⅳ |
MODEL | MX250 MOTOCROSS |
ENGINE | |
ENGINE MODEL | ZS177MM |
ENGINE STYLE | Liquid cooled, single cylinder, DOHC, water cooled, 4 volves, 4 stroke |
DISPLACEMENT | 249.6cc |
BORE×STROKE | 77×53.6mm |
MAX POWER | 28kw/11500rpm |
MAX TORQUE | 25N.m/9000rpm |
COMPRESS RATIO | 14:1 |
CLUTCH STYLE | Wet multi-disc, 6 gears |
CLUTCH OPERATING MODE | Mechanical cable |
THROTTLE STYLE | Mechanical throttle |
POWER MODE | Standard |
FUEL SUPPLY | Close-loop EFI BOSCH |
CHASSIS/SUSPENSION/BRAKE | |
CHASSIS | HC700 steel, Diamond shape, dual-wing beam, Aluminum sub chassis |
HANDLE BAR | Intergrated |
REAR FORK | Aluminum double swing arm |
FOOTREST SUPPORT | Aluminum alloy |
WHEEL | Spoke wheel |
FRONT TIRE | 80/100 -21 CST |
REAR TIRE | 100/90 -19 CST |
FRONT SUSPENSION | Compression rebound, adjustable, upside down YUAN |
REAR SUSPENSION | Compression rebound, adjustable,external airbag YUAN |
F/R SUSPENSION STROKE (mm) | 305/134 |
FRONT BRAKE | Single disc, 2-piston opposed caliper TAISKO |
REAR BRAKE | Single disc, single piston caliper TAISKO |
ABS&CBS | – |
BASIC PARAMETER | |
L╳W╳H mm | 2168×805×1265 |
STEERING ANGLE ° | 38.5° |
RAKE ANGLE ° | 28° |
REACH DISTANCE mm | 130 |
WHEEL BASE mm | 1370 |
SEAT HEIGHT mm | 960 |
GROUND CLEARANCE mm | 310 |
FUEL TANK VOLUME L | 6L |
CURB WEIGHT kg | 108 |
ELECTRIC SYSTEM | |
KEY | None |
BATTERY | 12V2.7AH Lithium |
HEAD LIGHT | – |
DRL | – |
TAIL LIGHT | – |
WINKER | – |
METER | – |
FEATURE | |
QUICK SHIFT | – |
TRACTION CONTROL | – |
MAX SPEED | 140km/h |
0-100 KM/H START ACCELERATION | – |
FUEL CONSUMPTION | – |
