| 510F SPECIFICATION | |
| PRODUCT NAME | 510F |
| REGION | International |
| EMISSION STANDARD | Euro-V |
| MODEL | KY510F |
| ENGINE | |
| ENGINE MODEL | Z272MR |
| ENGINE STYLE | Dual cylinders, vertical, DOHC, liquid-cooled |
| DISPLACEMENT | 498cc |
| BORE×STROKE | 72×61.2mm |
| MAX POWER | 35KW/8500rpm |
| MAX TORQUE | 45N·m/7000rpm |
| COMPRESS RATIO | 10.6:1 |
| CLUTCH STYLE | Wet multi-disc, sliding clutch |
| CLUTCH OPERATING MODE | Mechanical cable |
| THROTTLE STYLE | Mechanical throttle |
| POWER MODE | Standard |
| FUEL SUPPLY | BOSCH EFI |
| CHASSIS/SUSPENSION/BRAKE | |
| CHASSIS | Diamond shape, dual-wing beam |
| HANDLE BAR | Intergrated aluminum alloy |
| REAR FORK | Aluminum alloy single swing arm |
| WHEEL | Aluminum alloy |
| FRONT TIRE | 110/80R18 |
| REAR TIRE | 160/60R17 |
| FRONT SUSPENSION | φ41mm preload inverted adjustable KYB |
| REAR SUSPENSION | Monoshock preload adjustable KYB |
| F/R SUSPENSION STROKE (mm) | |
| FRONT BRAKE | Dual floating discs , 2-piston calliper/ABS |
| REAR BRAKE | Single disc, 1-piston calliper/ABS |
| ABS&CBS | Dual ABS |
| BASIC PARAMETER | |
| L╳W╳H mm | 2110×895×1145 |
| STEERING ANGLE ° | 35° |
| RAKE ANGLE ° | 25.5° |
| REACH DISTANCE mm | 106 |
| WHEEL BASE mm | 1440 |
| SEAT HEIGHT mm | 805 |
| GROUND CLEARANCE mm | 210 |
| FUEL TANK VOLUME L | 18L |
| CURB WEIGHT kg | 194 |
| ELECTRIC SYSTEM | |
| KEY | Normal key |
| BATTERY | 12V8.6AH Lithium |
| HEAD LIGHT | LED |
| DRL | LED |
| TAIL LIGHT | LED |
| WINKER | LED |
| METER | LCD |
| NAVIGATION | – |
| FEATURE | |
| QUICK SHIFT | – |
| TRACTION CONTROL | – |
| MAX SPEED | 170km/h |
| 0-100 KM/H START ACCELERATION | – |
| FUEL CONSUMPTION | – |
