| 800X SPECIFICATION | |
| PRODUCT NAME | 800X PRO |
| REGION | International |
| EMISSION STANDARD | Chinese National Ⅳ |
| MODEL | ZF800GY |
| ENGINE | |
| ENGINE MODEL | Z288MW |
| ENGINE STYLE | Double cylinder, DOHC, liquid-cooled, 8 valves, 75° crankshaft |
| DISPLACEMENT | 799cc |
| BORE×STROKE | 88×65.7 |
| MAX POWER | 71kw/9000rpm |
| MAX TORQUE | 80N.m/7500rpm |
| COMPRESS RATIO | 13:1 |
| CLUTCH STYLE | Wet multi-disc, 6 gears, sliding clutch |
| CLUTCH OPERATING MODE | Mechanical cable |
| THROTTLE STYLE | Mechanical throttle |
| POWER MODE | Eco/Sport/Rain |
| FUEL SUPPLY | Close-loop EFI |
| CHASSIS/SUSPENSION/BRAKE | |
| CHASSIS | Diamond shape, dual-wing beam, separated chassis |
| HANDLE BAR | Intergrated aluminum alloy |
| REAR FORK | Aluminum double swing arm |
| FOOTREST SUPPORT | Aluminum alloy |
| WHEEL | Aluminum alloy spoke wheel |
| FRONT TIRE | 90/90-21 PIRELLI |
| REAR TIRE | 150/70-R18 PIRELLI |
| FRONT SUSPENSION | φ48mm Preload adjustable damping, KYB |
| REAR SUSPENSION | Preload adjustable damping KYB |
| F/R SUSPENSION STROKE (mm) | 240/240 |
| FRONT BRAKE | Double disc, opposed 4-piston calliper/ABS |
| REAR BRAKE | Single disc, 1-piston calliper/ABS |
| ABS&CBS | Dual ABS |
| BASIC PARAMETER | |
| L╳W╳H mm | 2238×880×1399 |
| STEERING ANGLE ° | 35° |
| RAKE ANGLE ° | 26.15° |
| REACH DISTANCE mm | 112 |
| WHEEL BASE mm | 1510 |
| SEAT HEIGHT mm | 875 |
| GROUND CLEARANCE mm | 275 |
| FUEL TANK VOLUME L | 20L |
| CURB WEIGHT kg | 185 |
| ELECTRIC SYSTEM | |
| KEY | Normal key |
| BATTERY | 12V6AH Lithium |
| HEAD LIGHT | LED |
| DRL | LED |
| TAIL LIGHT | LED |
| WINKER | LED |
| METER | 7″ TFT |
| NAVIGATION | Mobile screen projection |
| FEATURE | |
| QUICK SHIFT | Available |
| TRACTION CONTROL | Available |
| MAX SPEED | 210km/h |
| 0-100 KM/H START ACCELERATION | – |
| FUEL CONSUMPTION | – |
| TIRE PRESSURE MONITORY | Available |
| STEERING DAMPING | Available |
